Amidst the fierce competition in the high bandwidth memory (HBM) sector, Samsung Electronics has managed to regain some prestige in its ongoing rivalry with SK HynixThe company has made significant strides in developing its HBM4 memory logic chips, announcing completion of the design phase as early as January 5, 2024. This news comes from credible sources within the supply chain, marking an important milestone in Samsung's quest to reclaim a dominant position in the HBM market.

This latest deal involves Samsung's Foundry business employing a 4nm process for the trial production of these chipsAs they finalize performance validation for these logic chips, they plan to provide samples of HBM4 for testing purposesAt the core of these developments lies the logic chip, which is pivotal in controlling the multi-layered DRAM stacks within HBM technology.

The essence of HBM's superiority is rooted in its innovative 3D stacking capabilities—integrating multiple DRAM chips vertically to optimize performance

By implementing silicon via technology, HBM facilitates rapid signal transmission between chips, effectively minimizing data transfer distances and latencyAs a result, processors receive data at exceptionally high bandwidths, which is critical for applications such as high-performance computing, artificial intelligence, and graphics processing.

Previously, SK Hynix’s ascension to the forefront of the HBM market had compelled Samsung to re-evaluate its strategiesThroughout 2023, Samsung's DS division undertook numerous adjustments—reportedly four to five modifications—to reorganize its technological framework and leadershipThis series of changes demonstrated Samsung's determination to gradually reclaim its previously held industry stature, with HBM4 being positioned as a pivotal element in this endeavor.

Previously reigning as the leader in HBM3, Samsung found itself eclipsed by SK Hynix, necessitating a strategic overhaul to keep pace with its rival

• Has the Bank Recovered From Its 60% Plunge?
• Fed Influence Fuels Southeast Asian Rate Cuts
• US Debt Risks Global Economy
• Market Rallies Amid Economic Weakness
• China-Singapore FTA Gets Further Boost

The company is intent on re-establishing its reputation in the rapidly evolving HBM landscape by employing novel technological solutions tailored for the upcoming generationThis includes a robust focus on the distinct capabilities offered by their proprietary 4nm process, which they hope will level the playing field with SK Hynix.

The competitive edge that Samsung seeks to establish primarily derives from SK Hynix's lack of foundry capabilitiesSources indicate that SK Hynix has teamed up with TSMC to leverage its 5nm process for HBM4's Base die design and manufacturingComparatively, Samsung is proceeding with its independent development, planning to utilize this more advanced fabrication process to ensure exceptional performance and efficiency.

Despite the palpable excitement surrounding HBM technology's advancements, concerns linger regarding the energy consumption associated with these rapidly progressing innovations

As Samsung approaches the ceiling of HBM4's capabilities, power consumption and heat generation emerge as significant considerations, particularly pertaining to the Base die, which is typically the hottest component in an HBM stackIn pursuit of maintaining a competitive edge, Samsung aims to exploit the advantages of its 4nm technology in an effort to mitigate these thermal challenges.

Samsung's traditional prowess in managing the energy efficiency of high-process chips has often been overshadowed by TSMC's expertiseHence, a key question remains: will Samsung's aspirations of surpassing TSMC materialize? The answer will largely depend on the performance outcomes of the forthcoming HBM4 samplesFor all intents and purposes, despite achieving a faster design timeline, true performance superiority remains to be evaluated.

Samsung recognizes this nuance and has reportedly expressed an awareness of the need to refine its memory business strategies

They understand that while they may have temporarily triumphed in HBM4's Base die design through their 4nm process, surpassing SK Hynix's comprehensive capabilities is a more formidable challengeIn light of this, Samsung's strategy moving forward appears to involve leveraging next-generation 10nm (c) DRAM chips for stacking in HBM applications, distancing itself from SK Hynix's use of the now aging 10nm (b) DRAM.

Even if Samsung's lead might seem marginal, it remains a lead nonetheless, underscoring the competitive spirit that characterizes the high-tech landscapeIndustry insiders have suggested that Samsung plans to adopt a "hybrid bonding" technique for stacking 16 high, a significant advancement from the current max of 12 high for HBM4. In contrast, HBM3e variations offer configurations of 8 high and 12 highThis hybrid bonding technique, allowing chips to be stacked directly using copper without traditional bump connections, promises not only to reduce dimensions but also enhance performance.

In addition to its ambitious manufacturing and technological agendas, Samsung is rapidly enhancing its foundry operations

After trailing rivals in earlier generations, the imperative to expedite HBM4's rollout is paramount as it seeks to meet client demands swiftly and efficientlyIn parallel, SK Hynix is not resting on its laurels either; they are aiming to commence mass production of HBM4 by the end of 2025, establishing a competitive timeline identical to Samsung's.

Another significant development is that leading tech companies—Microsoft, Meta, Google, and even Tesla—are all eyeing the upcoming HBM4 memory chipsTesla has recently engaged with both Samsung and SK Hynix, expressing interest in acquiring samples of these cutting-edge memory solutions.

The integration of HBM4 into Tesla's Dojo supercomputing platform aims to dramatically accelerate the training of neural networks intended for fully autonomous driving capabilitiesFurthermore, HBM4's deployment is anticipated in Tesla's data centers and future self-driving vehicles
